Incl all Starter, battery and VAT
There is general idea that
Diesel Generators last longer than petrol
ones. This is not quite right when it comes to air
cooled ones. You should not connect it to Geysers or stoves.
If you do not print the
Direction to our office
you shall have difficulty finding it.
Air cooled Generators are
made to work as standby units only.
|
Special price till 19th Feb 2012
|
Price 5KVA: R
9,195
Incl VAT and battery with
Price 6.5 KVA with
Automatic start add
R11,600ExcludingVAT
Price of 4KVA: R 7,195
Incl VAT and battery
( If you want warrantee for battery add R250
incl)
Prices
are subject to
change as a result of exchange rate
|
|
|
Order form, Proforma invoice
4 months warranty for this item.
No hot plate Geyser , Iron ,
Stove welding machine can not be used with
this Generator.
100 AMP 3 Phase
manual Changeover switch with heavy duty
wall mount box R 1260 incl VAT. |
|
Product
Description
MODEL
SILENT TYPE
5/6GF-LDE
Generator
Type:
Revolving
field type 2
pole
generator
Frequency
(HZ) :50 60
Cont Output
(KW): 4.2 /5
Voltage (A.C)
(V) : 230
/240(120)
Current (A.C) (V)
:18.3
/20.8(41.7)
Engine Speed
(r/min):3000
/3600
Phase
:Single
phase
Power factor
:1
Excitation
system:
Controlled
Constant
Self-excitation
D.C output
V/A
:12V/8.3A
Operation
Capacity: 12
hour
Constant
Operation
Coupling
:Straight
shaft
coupling
Engine
Model:186FGE
Type: Direct
injection
Vertical,4-cycle,air-cooled
diesel
engine
Displacement
cc (cu. in.)
:406(24.78)
Max. output
(KW/rpm):6.6
/7.35
Cont. output
(KW/rpm):5.9
6.6
Starting
system:
Recoil
Govenor
system
:Centrifugal
weight
system
Fuel Diesel:
light fuel
(BS-AL or
equivalent)
Fuel tank
capacity (L)
:16
Lube oil
capacity
(L): 1.65
Bore x
Stroke (mm):
86x70
Protection
System: Low
oil, Warming
System/Stop
Device (not
for
L-series)
UNIT Noise
level :at 7m
dB (A) 70
dimensions (LxWxH)
mm
:905X520x680
Dry weight
(kg): 165
Big
water cooled Generators 25 KVA
![]() For long period water cooled Generators that
are 1500 RPM must be used. |
|
